ALCATEL 2010 SD ROTARY VANE VACUUM PUMP 6.8 CFM

Rotary Vane Pumps

Two Stage Rotary Vacuum Vacuum Pump

Pumping speed and ultimate pressure are based on 60 Hz operation.

Alcatel 2010 SD Pascal

1 unit @ Best Price

Make: Alcatel

Model: 2010 SD Pascal

Item ID: 163508

Manufacturer Alcatel
Model 2010 SD Pascal
Pumping Speed 6.8 CFM (192.2 l/m)
Ultimate Pressure 0.15E-2(En) torr (0.20E-2 mbar)
Inlet Flange KF 25.0 mm (0.984 in)
Exhaust Flange KF 25.0 mm (0.984 in)
Duty--Service Normal
Two-Stage YES
Gas Ballast Yes
Direct Drive Yes
Oil Type Hydrocarbon
Other Information

Single phase 115/230VAC 50/60 Hz

Filled with Edwards Ultra Grade 19 oil

Condition Excellent
Power Requirements 115/ 230 V 4.0 A 2.0 A(2) 50/60 Hz 1 Phase
CE Marked YES
Exterior Dimensions
Width 6.500 in (16.5 cm)
Depth 17.500 in (44.5 cm)
Height 9.000 in (22.9 cm)
Weight 54 lb (24 kg)
@
$
=
