ALCATEL DRY HELIUM LEAK DETECTOR
Helium Leak Detectors
Dry Helium Leak Detector
1 unit @ Best Price
Make: Alcatel
Model: ASM 180 TD
Item ID: 183220
| Manufacturer | Alcatel |
| Model | ASM 180 TD |
| High Vacuum Pump Type | Turbomolecular Pump |
| Minimum Detectable Helium Leak Rate | 0.2E-10 atm-cc/sec |
| Maximum Detectable Leak Rate | 0.10E0 atm-cc/sec |
| Inlet Port for Auxiliary Pump | No |
| Test Port Connection | KF 40 |
| Start Up Time | 3 Min. |
| Helium Pumping Speed at Inlet | 4.40 l/s (9.32 CFM) |
| Remote Control Capabilities | Yes |
| Interface | RS 232 |
| Audio Alarm with Variable Pitch | Yes |
| Detectable Masses | 4 AMU |
| Internal Calibrated Leak | Included |
| Built-In Roughing Pump | Included |
| Liquid Nitrogen Trap | Not Included |
| Accessories | Equipped with gas line "Bullet test option"
|
| Other Information | Smallest detectable signal at full pumping speed 5E-12 (atm·cc/s) |
| Power Requirements | 115 V 60 Hz 1 Phase |
| Exterior Dimensions | |
| Width | 23.000 in (58.4 cm) |
| Depth | 19.000 in (48.3 cm) |
| Height | 20.000 in (50.8 cm) |
| Weight | 228 lb (103 kg) |
