ELECTRONIC MEASUREMENT INC. DC POWER SUPPLY, 300V, 16A

DC Power Supplies

DC Power Supply

7 unit s @ $2,650.00

Make: Electronic Measuremt

Model: EMS 300-16-2-D LB-10T-1401

Item ID: 3703

Manufacturer	Electronic Measuremt
Model	EMS 300-16-2-D LB-10T-1401
Maximum Output Voltage	300.00 Volts
Maximum Output Current	16.00 Amps
Maximum Output Power	4.80 kW
Regulation Modes	Constant Current Constant Voltage
Ripple	150
Panel Meters	Digital
Control Type	Analog Setpoint
External Cooling	Forced Air Cooled
Other Information	Model EMS 300-16-2-D-LB-10T-1401 0-5V voltage and current remote control 0-5V voltage and current monitor scale Stability 0.05% Regulation 0.1% Watts 5000 Programmable This power supply has option -1401: “Fast discharge option”. Output electrolytic filtering capacitor is replaced with polyester one with much smaller value to achieve fast discharge. As a result, output voltage is less filtered, ripple P-2-P voltage @ full power is 5.7 V. Standard power supply without -1401 option specification: ripple P-2-P voltage 0.15 V.
Extended Description	Details at 83473000_EMS_STD Rev J.pdf
Power Requirements	190-250 V 24.0 A 50/60 Hz 3 Phase
Condition	Excellent
Exterior Dimensions
Width	19.000 in (48.3 cm)
Depth	22.000 in (55.9 cm)
Height	5.250 in (13.3 cm)
Weight	46 lb (21 kg)
