Brewer Science Inc. Programmable Automated Coat/Bake Track System

Quoted on requestWorking & warranted
Condition
Used See details
Brand
Brewer Science
MPN
CEE 4000
SKU
77000
Availability
2 in stock
Quantity
Make Inquiry

Shipping, sale coverage & payments

Shipping:
Ships from Scotia, NY. Method, cost and timing confirmed on your quote. Shipping policy
Lead Time:
We’ll confirm exact timing when we send your quote.
Sale Coverage:
Working & Warranted: 90-day warranty. View terms
International Orders:
Case by case; export controls may affect eligibility. Contact us
Payments:
Credit card via Stripe, or purchase order. Payment Information
Independent Reseller:
Capovani is not an authorized distributor or representative of the original manufacturer.
Capovani Brothers Inc.

Shop with confidence

Family-owned since 1988. Equipment stocked in Scotia, NY. About Capovani

Item description

Up to 200 mm round or 6" square substrates

0-6000 rpm spin range

1-30,000 rpm/sec acceleration - unloaded

Hot chuck size: 10" x 10"

Temperature range: 50-300°C

Temperature control: programmable digital PID

Technical specifications

Number of Cassette Elevators2
Number of Photoresist Coat Stations1
Number of Photoresist Dispenses5
Number of Hot Plates1
Power Requirements120/220 V 50/60 Hz 1 Phase
Operating Air Pressure70.00 PSI (482,671.00 N/sq m)
Vacuum Required25.00 in Hg (634.99 mm Hg)
Weight380 lb (172 kg)

Wafer Size Range

Minimum100 mm
Maximum200 mm

Exterior Dimensions

Width36.000 in (91.4 cm)
Depth41.000 in (104.1 cm)
Height18.000 in (45.7 cm)

Condition & testing notes

Previously in service and offered for secondary-market resale.
