Neslab RTE-7 Digital Plus Bath Circulator
Quoted on requestWorking & warranted
- Condition
- Used See details
- Brand
- Neslab
- MPN
- RTE-7 Digital Plus w/ Automatic Refill
- SKU
- 170043
- Availability
- 1 in stock
Shipping, sale coverage & payments
- Shipping:
- Ships from Scotia, NY. Method, cost and timing confirmed on your quote. Shipping policy
- Lead Time:
- We’ll confirm exact timing when we send your quote.
- Sale Coverage:
- Working & Warranted: 90-day warranty. View terms
- International Orders:
- Case by case; export controls may affect eligibility. Contact us
- Payments:
- Credit card via Stripe, or purchase order. Payment Information
- Independent Reseller:
- Capovani is not an authorized distributor or representative of the original manufacturer.
Shop with confidence
Family-owned since 1988. Equipment stocked in Scotia, NY. About Capovani
Item description
RS-232/485 interface, 1/8" nitrogen purge, timer, temperature offset, adjustable temperature cut off, connector for optional external RTD sensor, auto refill option installed.
2000W heater, 500W cooling capacity.
Tested.
230VAC 50 Hz only.
BOM# 271125200100 CE label
Technical specifications
| Minimum Temperature | -25 ºC (-13 ºF, 248.00 ºK) |
| Maximum Temperature | 150 ºC (302 ºF, 423 ºK) |
| Cooling Capacity | 500 W (1,705 BTU/hr) |
| Heating Capacity | 2,000 BTU/hr (0.59 kW, 0.79 HP) |
| External Cooling | Forced Air Cooled |
| Pump type/Model | Z |
| Max Flow | 4 GPM (15.20 l/m) |
| Inlet Connection | 1/4-npt |
| Outlet Connection | 1/4-npt |
| Capacity/Liquid | 7.20 L (1.90 gal) |
| Refrigerant Type & Quantity | Suva-R-134A -6-oz |
| Power Requirements | 230 V 12.0 A 50 Hz 1 Phase |
| CE Marked | YES |
| Weight | 64 lb (29 kg) |
Temperature Control
| Control Stability | ± 0.010 ºC |
Heat/Cool Controls
| Control Type | Programmable |
| Interface | RS 232 |
| Controller Manufacturer/Model | Neslab Digital Plus |
Bath/Tank Dimensions
| Length | 7.2500 in (18.42 cm, 184.2 mm) |
| Width | 6.5000 in (16.51 cm, 165.1 mm) |
| Depth | 6.0000 in (15.24 cm, 152.4 mm) |
Exterior Dimensions
| Width | 9.250 in (23.5 cm) |
| Depth | 19.000 in (48.3 cm) |
| Height | 23.750 in (60.3 cm) |
Condition & testing notes
Previously in service and offered for secondary-market resale. Item has been tested and found to be working.
