Siemens 3RW4047-1BB05 SIRIUS Soft Starter, 106A, 75kW, 400-600V
$2,000.0030 day return
- Condition
- New (open box) See details
- Brand
- Siemens
- MPN
- 3RW4047-1BB05
- SKU
- CID1413
- Availability
- 1 in stock
Shipping, sale coverage & payments
- Shipping:
- Ships from Scotia, NY. UPS parcel within 3 business days of order confirmation; cost calculated at checkout. Shipping policy
- Sale Coverage:
- 30 Day Return: 30-day functional return as listed. View terms
- International Orders:
- Case by case; export controls may affect eligibility. Contact us
- Payments:
- Credit card via Stripe, or purchase order. Payment Information
- Independent Reseller:
- Capovani is not an authorized distributor or representative of the original manufacturer.
Shop with confidence
Family-owned since 1988. Equipment stocked in Scotia, NY. About Capovani
Item description
106 A AC-3 at <=40 C; 98 A FLA at <=50 C. 400-600 V, 50/60 Hz; 24 V AC/DC control. 55 kW at 400 V, 75 kW at 600 V; 75 HP at 460/575 V. Short-circuit rating 10 kA at 600 V; max fuse 300 A Class J; screw terminals.
Technical specifications
| Us | 24 V |
| IP | IP00 |
| IEC/EN 60947-4-2 | CLASS 10 |
| Ue | 400-600 V 50/60 Hz |
| Ie | 106 A <=40 C |
| P AC-3(kW) | 55 at 400 V; 75 at 600 V |
| Ui | 600 V / Uimp: 6 kV |
| IEC 60947-5-1 | AC-15: 3 A/230 V; DC-13: 1 A/24 V |
| Ui | 300 V |
| Uimp | 4 kV |
| V AC | 460 / 575 |
| 3PH (HP) | 75 / 75 |
| FLA | 98 <=50 C |
| Surrounding air temp. | 50 C |
| SHORT CIRCUIT | 10 kA, 600 V |
| MAX FUSE | 300 A CLASS J |
| Wire | 75 C CU WIRE ONLY |
| TERMINAL KIT | 3RT1946-4G |
| AUX.CONT. | B300 - R300 |
| Product family | 3RW40 soft starters |
| Size | S3 |
| Terminals | Screw terminals |
Condition & testing notes
Unused inventory opened for inspection or photography. The item is from old surplus stock.
