Womac Evolution Motion 0-90 GPM, 3500 PSI Variable Flow Hydraulic Power Unit

$67,500.0030 day return

Condition: Used
Brand: Womac Evolution Motion
MPN: 0-90 GPM, 3500 PSI
SKU: GID_5467
Availability: 1 in stock

Item description

System Performance Summary

NB: This summary Is solely based on the components installed and should be used as an approximation only. Please due your own calculations

Main Circuit Flow: 0–90 GPM (variable displacement, based on 190 cc/rev pump @ 1785 RPM)
Main Circuit Pressure: Up to ~3,500 PSI working (3,800 PSI theoretical limit with 200 HP motor; components rated to 300 bar / 4,350 PSI)
Auxiliary / Pilot Circuit Flow: ~8.5 GPM (from 18 cc/rev pump @ 1760–1785 RPM)
Auxiliary / Pilot Circuit Pressure: Matches system setting (up to ~3,500 PSI)
Cooling System Motor Power: ~2–3 HP (460 V TEFC motor driving air-to-oil cooler fan)
Reservoir Capacity: Approximately 130 gallons of hydraulic fluid
Accumulator Pre-Charge Pressure: 3,000 PSI (Nitrogen)
System Operating Pressure Rating: Components qualified to 5000 PSI (MAWP via Hydac valving)
Total Installed Power: ≈ 208 HP (200 HP main + 5 HP auxiliary + ~3 HP cooler fan)
Hydraulic Horsepower Output: ≈ 171 HP (85% overall system efficiency typical for this configuration)
System Type: Dual-pump, closed-loop pressure-compensated hydraulic power unit

Component Summary

Main Motor: Hyundai Heavy Industries – IEEE200-18-447TCBB – 200 HP, 460 V, 1785 RPM, Frame 447TC, TEFC, 96.3% efficiency, 2018.05
Secondary Motor: Hyundai Heavy Industries – HKS184PR2388N – 5 HP, 460 V, 1760 RPM, Frame 184TC, TEFC, 2018.11
Cooler Motor: WEG – (tag partially visible) – ~2–3 HP, 460 V TEFC
Main Pump: Rexroth – A10VO190LRDH2/11R-NZDI2K52-E – 190 cc/rev axial piston variable displacement
Auxiliary Pump: Rexroth – A10VSO18DR/31R-PPA12N00 – 18 cc/rev axial piston pump with pressure compensator
Pressure Manifold Valve: Rexroth – PUV4-1X/098RAL15VNC R900976294 (Made in Italy)
Directional Valve Assembly: Duplomatic – MERS-015D (SV340A / SV360A) – 300 bar rated
Accumulator: Hydac – 2654276 / Order No. 11186515 – 3000 psi nitrogen precharge
Isolation Valve: Hydac – SAF20M16-N330C S63 – 5000 psi MAWP, 20 mm bore, 2012 build
Reservoir: Custom Fabricated – HR-130A – ~130 gallon steel tank with dual desiccant breathers and sight gauge
Breathers/Filters: Des-Case – DC-Series Desiccant Breathers
Cooler Assembly: Air-to-Oil Heat Exchanger with WEG motor drive
System Builder: Womack Systems – Job 726325 – Date 9/26/2019
