Alcatel ASM 180 TD Dry Helium Leak Detector

Quoted on requestWorking & warranted
Condition
Used See details
Brand
Alcatel
MPN
ASM 180 TD
SKU
183220
Availability
1 in stock
Make Inquiry

Shipping, sale coverage & payments

Shipping:
Ships from Scotia, NY. Method, cost and timing confirmed on your quote. Shipping policy
Lead Time:
We’ll confirm exact timing when we send your quote.
Sale Coverage:
Working & Warranted: 90-day warranty. View terms
International Orders:
Case by case; export controls may affect eligibility. Contact us
Payments:
Credit card via Stripe, or purchase order. Payment Information
Independent Reseller:
Capovani is not an authorized distributor or representative of the original manufacturer.
Capovani Brothers Inc.

Shop with confidence

Family-owned since 1988. Equipment stocked in Scotia, NY. About Capovani

Item description

Equipped with gas line "Bullet test option"

Turbo pump

Polished stainless steel exterior (UCT option)

Smallest detectable signal at full pumping speed 5E-12 (atm·cc/s)

Helium signal reading range 2E-11 to 1E-1(atm·cc/s)

Technical specifications

High Vacuum Pump TypeTurbomolecular Pump
Minimum Detectable Helium Leak Rate0.2E-10 atm-cc/sec
Maximum Detectable Leak Rate0.10E0 atm-cc/sec
Inlet Port for Auxiliary PumpNo
Test Port ConnectionKF 40
Start Up Time3 Min.
Helium Pumping Speed at Inlet4.40 l/s (9.32 CFM)
Remote Control CapabilitiesYes
InterfaceRS 232
Audio Alarm with Variable PitchYes
Detectable Masses4 AMU
Internal Calibrated LeakIncluded
Built-In Roughing PumpIncluded
Liquid Nitrogen TrapNot Included
Power Requirements115 V 60 Hz 1 Phase
Weight228 lb (103 kg)

Exterior Dimensions

Width23.000 in (58.4 cm)
Depth19.000 in (48.3 cm)
Height20.000 in (50.8 cm)

Condition & testing notes

Previously in service and offered for secondary-market resale.
