Power Supply (not shown) with interconnect cable.
Gauges and cables are not included, inquire, please.
TC gauge compatible types: G-P 270006, Comptech TVT-6000, or Teledyne-Hastings DV-6M, DV-6R, DV-36, DV-20.
Ion gauge cables see items 179524, 209733
More information can be found in the manual
Granville Phillips 307 Ion Gauge Controller Manual
307015 standard non-UHV electrometer
307005 resistive degas option
307006 option for sequential operation of second ion gauge
307014, 307059 modules for the total of three thermocouple gauges readout, pressure range 10-3 Torr to 1 Torr Nitrogen or air equivalent.
307082 one channel set point process control module (TC channel 3), can be upgraded to 6 channels for $250
Optional 307019 RS232 communications module, add $250
Optional remote I/O connector, if available, add $100
Can be converted to 230VAC operation, request when ordering
Dimensions and weight
Control Unit
Width 241 mm 9.5 in
Height 89 mm (3.5 in.)
Depth 356 mm (14 in.) includes 76 mm (3 in.) for connectors and cables
Weight 3 kg (6.5 lb.)
Power Unit
Width 203 mm (8 in.)
Height 89 mm (3.5 in.)
Depth 330 mm (13 in.) includes 89 mm (3.5 in.) for connectors and cables
Weight 4 kg (8.5 lb.)
