Nupro SS-4BK-VCR Bellows-Sealed Valve, 316 SS, 1/4 in Male VCR
$300.0030 day return
- Condition
- Brand new See details
- Brand
- Nupro Company
- MPN
- SS-4BK-VCR
- SKU
- CID1424
- Availability
- 1 in stock
Shipping, sale coverage & payments
- Shipping:
- Ships from Scotia, NY. UPS parcel within 3 business days of order confirmation; cost calculated at checkout. Shipping policy
- Sale Coverage:
- 30 Day Return: 30-day functional return. View terms
- International Orders:
- Case by case; export controls may affect eligibility. Contact us
- Payments:
- Credit card via Stripe, or purchase order. Payment Information
- Independent Reseller:
- Capovani is not an authorized distributor or representative of the original manufacturer.
Shop with confidence
Family-owned since 1988. Equipment stocked in Scotia, NY. About Capovani
Item description
316 SS body, 321 SS bellows, PCTFE conical stem tip, straight 2-way flow, Cv 0.36, 1/4 in male VCR face seal ends. Rated -20F to 200F; 1000 psig @ 100F, 830 psig @ 200F. Plate: cleaned to NC-11, helium leak tested.
Technical specifications
| CLEANED TO | NC-11 |
| HELIUM LEAK TESTED | Yes |
| Actuator Type | Manual |
| Bellows Material | 321 Stainless Steel |
| Body Material | 316 Stainless Steel |
| Body Seal | Gasket with soft seat |
| Connection 1 Size | 1/4 in. |
| Connection 1 Type | Face Seal (Metal Gasket) Male VCR |
| Connection 2 Size | 1/4 in. |
| Connection 2 Type | Face Seal (Metal Gasket) Male VCR |
| CV Maximum | 0.36 |
| Flow Pattern | Straight (2-way) |
| Gasket | PTFE-Coated 316 SS Gasket |
| Handle Color | Green |
| Handle Style | Phenolic Round Handle |
| Maximum Temperature, °F (°C) | 200 (93) |
| Max Temperature Pressure Rating | 200°F @ 830 PSIG /93°C @ 57.1 BAR |
| Minimum Temperature, °F (°C) | -20 (-28) |
| Room Temperature Pressure Rating | 1000 PSIG @ 100°F /68.9 BAR @ 37°C |
| Service Class | General |
| Stem Tip Material | PCTFE |
| Stem Type | Conical |
| Surface Finish | Standard |
Condition & testing notes
Never used inventory in brand new condition. The item is from old surplus stock.
