Flow Factor 1 (Cv):0.96
Product Series:Gold Ring Series
Valve Type:2-Way
Function:Normally Open (NO)
Coil Type:1/2" NPT Conduit, 18" Leads, Class F, NEMA 4
Port Size:1/4 inch
Input Voltage:110/50-120/60
Body Material:Brass
Seal Material:NBR
Voltage (V):110/50-120/60
Orifice 1 Size:9/32 inch
Flow Coefficient 1:0.96 Cv
Power Consumption:11 W (AC)
Coil Type:1/2" NPT Conduit, 18" Leads, Class F, NEMA 4X
Maximum Pressure Differential:30 psi (AC)
Number of Ports:2
Actuation Type:Direct Acting
Media:General Purpose for Air, Liquids and Gases
Port Type:NPT
Orifice 2 Size:n/a
Flow Coefficient 2:n/a
Minimum Pressure Differential:0 psi
Minimum Fluid Temperature:0 °F
Maximum Fluid Temperature:180 °F
Coil Specifications Met:Class F
Power (Watts):11 Watt (AC)
Maximum Pressure Differential (psi):30 psi (AC)
Orifice 1 Size (inch):9/32
Seal Material:NBR
