You may not receive the exact item shown in photos, but all items are in similar condition unless otherwise specified.
Oerlikon Leybold D25B Rotary Vane Vacuum Pump 200-240/380-480, 3 Phase
$1,100.00As-is no return
- Condition
- Used See details
- Brand
- Oerlikon Leybold
- MPN
- D25B
- SKU
- 186387
- Availability
- 11 in stock
Quantity
Shipping, sale coverage & payments
- Shipping:
- Ships from Scotia, NY. Freight, ready within 3 to 5 business days of order confirmation; you arrange the carrier or we can coordinate it.
- Sale Coverage:
- As-is No Return: No return; final sale. View terms
- International Orders:
- Case by case; export controls may affect eligibility. Contact us
- Payments:
- Credit card via Stripe, or purchase order. Payment Information
- Independent Reseller:
- Capovani is not an authorized distributor or representative of the original manufacturer.
Shop with confidence
Family-owned since 1988. Equipment stocked in Scotia, NY. About Capovani
Item description
Part No.: 11276
Power input: 200/380-400V, 50Hz -- 200-240/380-400V, 50Hz
Power input: 208-240/416-480 V, 60Hz -- 200-240/380-480, 60Hz
Assume pump needs to be rebuilt
Technical specifications
| Pumping Speed | 20.9 CFM (590.6 l/m) |
| Ultimate Pressure | 0.15E-2(En) torr (0.20E-2 mbar) |
| Inlet Flange | KF 25.0 mm (0.984 in) |
| Exhaust Flange | KF 25.0 mm (0.984 in) |
| Duty--Service | Normal |
| Two-Stage | YES |
| Gas Ballast | Yes |
| Direct Drive | Yes |
| Motor Horsepower | 1.5 HP |
| Rotational Speed | 1,725 RPM |
| Oil Type | Hydrocarbon |
| Oil Capacity | Maximum: 0.47 L (0.50 qt, 0.10 Br gal) |
| Power Requirements | 230/460 V 3.6 A 1.8 A(2) 50/60 Hz 3 Phase |
| Weight | 98 lb (44 kg) |
Exterior Dimensions
| Width | 9.750 in (24.8 cm) |
| Depth | 25.000 in (63.5 cm) |
| Height | 11.750 in (29.8 cm) |
Condition & testing notes
Previously in service and offered for secondary-market resale.
